Background technique:

A syringe is a common medical device. As early as the 15th century, Italian Katinel proposed the principle of the syringe. The needle or the liquid is mainly extracted or injected. Syringes can also be used to inject medical equipment, containers, scientific instruments such as some chromatography through rubber diaphragms.

Conventional syringe production mostly uses manual assembly of components or machine assembly, but the operation is inconvenient, and the loading needs manual startup monitoring, which affects the production rate. To this end, we propose a syringe automatic assembly machine.

Technical realization elements:

The utility model provides a syringe automatic assembly machine for the deficiencies of the prior art.

In order to achieve the above object, the utility model provides the following technical solutions: a main machine, a finished product export tray, a total loading tray, a cylinder silo, a cylinder centrifugal hopper, a needle vibrating hopper, a cylinder feeding tray, a cylinder needle assembly disc, a cylinder a body needle conveying tray, a rubber plug vibration hopper, a push rod rubber plug assembly tray, a push rod feeding tray, a push rod centrifugal hopper and a push rod silo, wherein the main unit is provided with a finished product outlet tray, and the finished product outlet tray side Connecting the total assembly tray, the photoelectric outlet counter is disposed at the outlet of the finished product outlet tray, and the push rod and the cylinder assembly pressing block are disposed at the joint between the finished product tray and the total assembly tray, and the finished disc side is fixedly connected to the finished slide rail, An unassembled cylinder filter is arranged on the finished slide rail, and a centrifuge centrifugal hopper is arranged on one side of the main body, and a cylinder silo is connected to one side of the centrifugal hopper of the cylinder body, and the cylindrical hopper side of the cylinder is connected to the cylinder body. a tray, a photoelectric switch is arranged at a junction of the cylinder centrifuge hopper and the cylinder feed tray, a needle vibration hopper is arranged on one side of the cylinder feed hopper, and the needle flat hopper is connected to one side of the needle vibration hopper. Needle flatter The cylinder feeding trays are all connected with the cylinder needle assembly tray, the cylinder needle assembly tray side is fixedly connected with the cylinder needle conveying tray, and the main body side is provided with a push rod centrifugal hopper, and the push rod centrifugal hopper is The side is connected to the push rod silo, the pusher centrifuge hopper side is connected with the push rod feeding tray, the main body side is provided with a rubber plug vibrating hopper, and the rubber plug vibrating hopper side is connected with the rubber plug flat feeding device, The push rod feeding tray and the rubber plug flatter are fixedly connected with the push rod rubber plug assembly disc, and the push rod rubber plug assembly disc and the barrel needle conveying tray are both connected to the total loading tray.

Preferably, a pressure regulating valve is disposed above one side of the main body, and a power supply terminal pile is disposed on one side of the main body.

Preferably, the outer surface of the cylinder centrifugal hopper is provided with a silo centrifuge hopper speed switch, and the universal wheel is fixedly mounted on the bottom of the main body, the cylinder centrifugal hopper and the push rod feeding tray.

Preferably, a control panel is disposed above the host, and an emergency stop switch is disposed on one side of the control panel, and an integrated circuit control box is disposed inside the host.

Compared with the prior art, the beneficial effects of the utility model are:

1. Using integrated circuit, the control panel has humanized LCD display, which is simpler and more convenient to operate.

2. Each feeding and discharging system is equipped with a photoelectric detection system to realize functions such as no material self-stop and material self-opening.

detailed description

The technical solutions in the embodiments of the present invention will be clearly and completely described in the following with reference to the accompanying drawings in the embodiments of the present invention. The embodiments are a part of the embodiments of the invention, and not all of the embodiments. All other embodiments obtained by those skilled in the art based on the embodiments of the present invention without creative efforts are within the scope of the present invention.

It should be noted that when an element is referred to as being "fixed" to another element, it can be directly on the other element or the element can be present. When an element is considered to be "connected" to another element, it can be directly connected to the other element or.
