The core components, for example, mechanical body, controllable system, servo motor, drive and big loading ball screw.so our electric injection molding machine can be provided the strong guarantee for forming your product
Share:
Plastic Injection Moulding Machine
High quality features
The hydraulic injection molding machine has realized “pressure valve ringcontrol” and “energy
supply and demand matching”, leading the injection molding machine in order To develop the trend!
Pressure valve ring control: The actual pressure is compared with the set pressure in real time and
corrected until the actual pressure is equal to the set pressure. Matching energy supply and demand:
How much energy does the injection molding machine do, how much energy the power system provides,
and very little energy loss.
Super energy saving
40% more energy efficient than the variable pump system. 60% energy saving than the fixed pump +
fixed speed motor (depending on the product can not save energy)
High precision, high response
The high-precision, high-sensitivity pressure sensor and rotary encoder realize closed-loop control of
pressure and flow, and the repeat progress error is less than 1%. The servo motor reaches the maximum
output power in only 0.05 seconds.
low noise
The noise value is within 78db. When the machine is not moving, the servo motor stops almost no noise.
TECHNICAL PARAMETERS
PRODUCT NAME | Plastic Injection Moulding Machine | |||||||||
SPECIFICATION | HHK170 | HHK230 | HHK270 | HHK330 | HHK380 | |||||
INJECTION UNIT | A | B | A | B | A | B | A | B | A | B |
Screw Diameter(MM) | 42 | 45 | 45 | 48 | 50 | 53 | 50 | 53 | 60 | 65 |
Theoretical capacity(cm³) | 270 | 352 | 270 | 352 | 481 | 540 | 481 | 540 | 820 | 963 |
Injection Weight(G) | 245 | 321 | 245 | 321 | 438 | 492 | 438 | 492 | 746 | 876 |
Injection Rate(G/S) | 410 | 471 | 530 | 603 | 585 | 657 | 585 | 657 | 500 | 586 |
Injection Pressure(MPA) | 172 | 150 | 150 | 132 | 170 | 151 | 170 | 151 | 219 | 186 |
Screw Speed(RPM) | 350 | 350 | 280 | 300 | 300 | |||||
CLAMPING UNIT | ||||||||||
Clamp Tonnage(KN) | 1700 | 2300 | 2700 | 3300 | 3800 | |||||
Toggle Stroke(MM) | 430 | 490 | 545 | 605 | 710 | |||||
Space Between Tie Bars(MM) | 470*470 | 532*532 | 580*580 | 680*680 | 720*720 | |||||
Max.Mold Height(MM) | 510 | 550 | 580 | 670 | 720 | |||||
Min.Mold Height(MM) | 170 | 200 | 210 | 250 | 250 | |||||
Ejector Stroke(MM) | 45 | 140 | 145 | 160 | 160 | |||||
Ejector Tonnage(KN) | 70 | 70 | 70 | 70 | 125 | |||||
Number Of Ejector Rods(PC) | 5 | 9 | 9 | 13 | 13 | |||||
OTHER | ||||||||||
Max.Pump Pressure(MPA) | 16 | 16 | 16 | 16 | 16 | |||||
Pump Motor Power(KW) | 22+22 | 30+22 | 30+30 | 30+37 | 37+37 | |||||
Hearter Power(KW) | 14.5 | 14.5 | 21 | 21 | 28 | |||||
Machine Dimension(M) | 5.6*1.6*2.0 | 5.8*1.8*2.0 | 6.3*1.8*2.0 | 6.8*1.95*2.1 | 7.6*2.1*2.2 | |||||
Machine Weight(T) | 7.8 | 8.4 | 10 | 12 | 17 | |||||
Oil Tank Capacity(L) | 450 | 505 | 560 | 630 | 750 | |||||
